TLV1812-Q1
供应商:
描述: 汽车类双通道微功耗高压比较器
物料参数
| Number of channels: | 2 |
| Output type: | Push-Pull |
| Propagation delay time (µs): | 0.42 |
| Vs (max) (V): | 40 |
| Vs (min) (V): | 2.4 |
| Vos (offset voltage at 25°C) (max) (mV): | 4 |
| Iq per channel (typ) (mA): | 0.005 |
| Input bias current (±) (max) (nA): | 1.2 |
| Rail-to-rail: | In |
| Rating: | Automotive |
| Operating temperature range (°C): | -40 to 125 |
| Features: | POR |
| VICR (max) (V): | 40.2 |
| VICR (min) (V): | -0.2 |
| TI functional safety category: | Functional Safety-Capable |
| Number of channels: | 2 |
| Output type: | Push-Pull |
| Propagation delay time (µs): | 0.42 |
| Vs (max) (V): | 40 |
| Vs (min) (V): | 2.4 |
| Vos (offset voltage at 25°C) (max) (mV): | 4 |
| Iq per channel (typ) (mA): | 0.005 |
| Input bias current (±) (max) (nA): | 1.2 |
| Rail-to-rail: | In |
| Rating: | Automotive |
| Operating temperature range (°C): | -40 to 125 |
| Features: | POR |
| VICR (max) (V): | 40.2 |
| VICR (min) (V): | -0.2 |
| TI functional safety category: | Functional Safety-Capable |
无库存
